Are you still using paper as the medium to transfer data between applications?
Taha Data Exchange (TDX)
It is time to change the traditional ways of Engineering Data Exchange
Background
Challenge
In 2004, the National Institute of Science and Technology (NIST) released a report on the impact of the lack of digital interoperability in the capital projects industry. Based on interviews and survey responses, $15.8 billion in annual interoperability costs were quantified for the capital facilities industry in 2002. see the report here or here. (Cost Analysis of Inadequate Interoperability in the U.S. Capital Facilities Industry)
On average about 20-30% of the Engineers and Designers time are spent on creating paper documents or interpreting these documents to transfer data from Computer-Aided Engineering (CAE) applications to Computer-Aided Design (CAD) applications.
A lot of these tasks can be replaced by what we call Computer-Aided Data Exchange (CAX).
As an example, a structural engineer will create a lot of sketches on paper to convey engineering information from their structural engineering application to the designers, so that they can implement, draft or model them in CAD applications.
This will be even more cumbersome when the design changes and the engineers have to repeat this tedious task all over again and again.
Solution
With the right CAX technology, you are not only able to save time on these data transfers, but also omit the human error factor which leads to time waste or even collateral damage costs.
Although a lot of effort has been made in the last 30 years to automate the data transfer between applications, what is called interoperability, still there is no off-the-shelf and ready-to-use product that can be utilised for such a purpose. Hence engineers and drafters still work with pen and paper even in today's world of robust technologies.
We at Taha Solutions are approaching this challenge with the Think Big Act Small (TBAS) methodology. We are creating a SaaS solution that can be used for these types of data transfers.
Although at the beginning our platform will be only covering some applications, we will continue adding more and more applications to it.
How it works
Sign in
SignUp or SignIn in our Platform
Upload
Upload your CAE file and Mapping File
Process
Application will provide you with the calculated cost based on the number of elements
Pay
you can chose Credit Card payment powered by Stripe or Pay by Paypal
Get Delivered
Download the transferred file and use it in your CAD system
Project Timeline
Mechanical Applications
Including Mechanical Applications into our platform
Piping Applications
Including Piping Applications into our platform
TDXP004, TDXE004, TDXP005, TDXE005,
TDXP006 and TDXE006 Product Launch
Personal and Enterprise Tier:
004: PDMS to Staad Pro Data Exchange
005: PDMS to Sesam GeniE Data Exchange
006: PDMS to Tekla Data Exchange
TDXP003, TDXE003 Product Launch
Personal and Enterprise Tier - Tekla to PDMS Data Exchange
TDXP002 and TDXE002 Product Launched
Personal and Enterprise Tier - Sesam GeniE to PDMS Pro Data Exchange
TDXE001 Product Lunched
Enterprise Tier - Staad Pro to PDMS Data Exchange
TDXP001 Product Lunched
Personal Tier - Staad Pro to PDMS Data Exchange
More robust data integration created in 2019 as a manual application which successfully transferred Staad (Structural Analysis) files to PDMS (3D Modelling Application) .mac files
The idea of data exchange between engineering applications started back in 1990
Many small integration projects have been delivered during those years
TDX Enterprise Solution for Staad to PDMS and Sesam GeniE to PDMS are ready to be used
But we can still help you with Personal Tier TDXP001 (manual data transfer) between Staad Pro and PDMS. Just click on the right button and send us an email with your Staad Pro file and Mapping File and we will send you the PDMS .mac file by email within 2-8 business hours when your payment process is completed.
Alternatively just create a new support ticket in our support portal and upload your Staad Pro and Mapping files over there.
Instruction on how to create mapping file can be found here.
Instruction on how to create a new ticket for Manual TDX Request on our support portal can be found here.
Pricing
TDXP (Personal Tier)
kr 7.70
/ element- For users with occasional use
(max 8 usage per month) - Maximum 2 modules
(No CRM power and support) - No customisation
- Email support
TDXE (Enterprise Tier)
kr 9.90
/ element- For organisations with frequent use
(more than 8 usage per month) - Access to all modules and features
(Unlimited CRM power and support) - Paid customisation
- Email support / Dedicated Support Manager
